| Image Sensor |
1/4" 1.0 Mega pixels CMOS |
| Chipset |
OV9712 + NVP2431H |
| Effective Pixels |
1280(H)×720(V) |
| Lowest illumination |
0.1Lux@?F1.2,AGC ON?, 0 Lux with IR |
| Electronic Shutter |
1/50s~1/100,000s |
| Video Frame Rate |
50/60fps@1280×720P |
| Video Output |
1 channel, AHD / CVBS, adjustable |
| Smart IR Control |
Support |
| Day/Night |
Auto(ICR) / Color / B/W / Extend |
| WDR |
Support |
| Noise Reduction |
2D DNR |
| SNR |
>60dB |
| Privacy Mask |
Support |
| OSD Menu |
Optional |
| Other Function |
AWB, AGC, BLC, HLC , Mirror, Defog |
| Power Supply |
DC12V±10% |
| Power Consumption |
< 5W |
| Working Environment |
-20°C~+60°C / Less than 95%RH |
| IR LED |
36 pcs ?5-850nm |
| IR Distance |
20-30 meters |
| Lens |
3.6/6/8 mm selectable |
| Transmission Distance |
Up to 500m via 75-3 coaxial cable |
