| Video/Audio Output | ||
|---|---|---|
| Live View Resolution: | PAL: 704x576; NTSC: 704x480 | |
| VGA Output: | 1-ch, resolution: 1024×768/60Hz | |
| CVBS Output: | 1, BNC (1.0 Vp-p, 75 Ω), Resolution: PAL: 704 × 576, NTSC: 704 × 480 | |
| Recording resolution: | 4CIF/DCIF/2CIF/CIF/QCIF | |
| Frame Rate: | 25 fps (P) / 30 fps (N) | |
| Video Bit Rate: | 32Kbps~2048Kbps, or user-defined | |
| Stream Type: | Video/Video&Audio | |
| Audio Output: | 1-ch BNC(Linear electrical level, 600Ω) | |
| Audio Bit Rate: | 16kbps | |
| Dual Stream: | Support | |
| Synchronous Playback: | 4-ch | |
| Hard Disk Driver | ||
|---|---|---|
| Interface Type: | 4 SATA Interfaces | |
| Capacity: | Up to 2TB capacity for each disk | |
| e-SATA Interface: | 1 eSATA interface | |
| External Interface | ||
|---|---|---|
| Network Interface: | 1 RJ45 10M/100M/1000M adaptive Ethernet Interface | |
| USB Interface: | 2 USB 2.0 Interfaces | |
| Serial Interface: | 1 RS-232 interface; 1 RS-485 interface | |
| Alarm Input: | 9-ch | |
| Alarm Output: | 4-ch | |
| LCD: | 5 inch | |
| General | ||
|---|---|---|
| Power Supply: | 100 - 240 V AC, 6.3 A, 50 - 60 Hz | |
| Consumption: | ≤ 45 W (without hard disk or DVD-R/W) | |
| Working Temperature: | -10°C~+55°C(14°F~131°F) | |
| Working Humidity: | 10%~90% | |
| Dimensions: | 280(D)×180(W)× 180(H)mm(11.02"(D)×7.09"(W)×7.09"(H)) | |
| Weight: | ≤ 5000 g (11.02 lbs) (without hard disk) | |
| Video/Audio Input | ||
|---|---|---|
| Audio Input: | 8-ch | |
| Video Compression: | H.264 | |
| Analog Video Input: | 8-ch | |
| PAL/NTSC Adaptive: | Support | |
| Video Input Interface: | BNC (1.0 Vp-p, 75Ω) | |
| Audio Compression: | OggVorbis | |
| Audio Input Interface: | BNC (2.0 Vp-p, 1 kΩ) | |
| Two-way Audio: | 1-ch BNC(2.0Vp-p, 1kΩ) | |
