| Camera |
Image Sensor |
1/3 type interline transfer CCD |
| Effective Pixels |
976 (H) x 582 (V) |
| Scanning Mode |
2:1 interlace |
| Scanning Area |
0.48 (H) x 0.36 (V) cm |
| Scanning Frequency |
Horizontal: 15.625 kHz Vertical: 50.00 Hz |
| Horizontal Resolution |
650 TV lines |
| Minimum Illumination |
Color: WV-CP310/WV-CP314 0.08 lx (F1.4, Sens Up: Off, AGC: High) WV-CP300/WV-CP304 0.08 lx (F1.4, Sens Up: Off, AGC: High) B/W: WV-CP310/WV-CP314 0.008 lx (F1.4, Sens Up: Off, AGC: High) WV-CP300/WV-CP304 0.05 lx (F1.4, Sens Up: Off, AGC: High) |
| Signal-to-Noise Ratio |
52 dB (AGC: OFF) |
| White Balance |
AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 8,000 K), ATW2 (2,400 ~ 8,000 K) |
| Light Control |
ALC/ALC+/ELC |
| AGC |
ON (LOW, MID, HIGH) / OFF |
| Electronic Shutter |
OFF (1/50), AUTO, 1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000, 1/120,000 |
| Electronic Sensitivity UP |
32x max. AUTO, 512x max. FIX |
| Day Night |
WV-CP310/WV-CP314 : Day & Night (IR) Off / Auto1 /Auto2 / On WV-CP300/WV-CP304 : Day & Night (Electorical) Off / Auto |
| Digital Noise Reduction |
High or Low |
| Scene File |
2 patterns |
| Video Motion Detection |
OFF / MOTION DET / SCENE CHANGE |
| Privacy Zone |
ON (1) / ON (2) / OFF, up to 8 zones |
| Auto Image Stabilizer |
ON / OFF |
| Camera Title |
16 alphanumeric characters |
| Synchronization |
Internal (INT) |
| Input/ Output |
Video Output |
1.0 V [p-p] / PAL composite 75 |
| Controller Interface |
Coaxial Multiplex System |
| General |
Setup Method |
OSD setup menu |
| Language |
English, Russian, German, French, Italian, Spanish, Chinese, Japanese |
| Safty / EMC Standard |
CE (EN60065, EN55022 ClassB, EN55024), GOST (GOST R 51558) |
| Power Source and Power Consumption |
WV-CP310/WV-CP300: 220-240 V AC, 50/60 Hz, 2.3 W WV-CP314/WP-CP304: 12 V DC, 180 mA 24 V AC, 50/60 Hz, 2.1 W" |
| Ambient Operating Temperature |
–10 °C ~ +50 °C (14 °F ~ 122 °F) |
| Ambient Operating Humidity |
90 % or less (without condensation) |
| Dimensions |
WV-CP310/WV-CP300: 7.2 cm (W) x 5.5 cm (H) x 10.1 cm (D) WV-CP314/WV-CP304: 7.2 cm (W) x 5.5 cm (H) x 8.1 cm (D) |
| Mass (approx.) |
WV-CP310: 180 g WV-CP314: 160 g WV-CP300: 180 g WV-CP304: 150 g |
| Finish |
ABS resin / Sail White |
