Support HD-TVI, AHD and analog cameras with adaptive access
Support 1080P lite mode enabled to realize the real-time
1080P lite and 720P lite resolution of TDV-5316-H1SV
Long transmission distance over coax cable
Up to 4/8-ch synchronous playback at 1080p resolution
Playback at up to 256X speed.
Description
| Video/Audio Input | Audio Input | 1-ch |
| Video Compression | H.264,H.264+ | |
| Analog and HD-TVI video input | 4/8/16-ch,BNC interface (1.0Vp-p, 75 Ω)connection | |
| Supported camera types |
Support HDTVI input: 3 MP, 1080p/25Hz, 1080p/30Hz,720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz |
|
| Support AHD input: 1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz | ||
| support CVBS input | ||
| IP Video Input | 1-ch Up to 2MP resolution (TDV-5308-H1SV), 2-ch Up to 2MP resolution (TDV-5308/16-H1SV) | |
| Video Input Interface | BNC (1.0 Vp-p, 75Ω) | |
| Audio Compression | G.711u | |
| Audio Input Interface | RCA (2.0 Vp-p, 1 kΩ) | |
| Two-way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) | |
| Video/Audio Output | CVBS Output | 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
| HDMI/VGA Output |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz HDMI (TDV-5316-H1SV): 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz 1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz |
|
| Recording resolution | When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; | |
| When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF | ||
| Video Bit Rate | 32 Kbps-6 Mbps | |
| Stream Type | Video/Video&Audio | |
| Audio Output | 1-ch RCA(Linear, 1kΩ) | |
| Audio Bit Rate | 64kbps | |
| Playback Resolution | 3 MP/1080p/720p/VGA/WD1/4CIF/CIF | |
| Synchronous Playback | 4/8/16-ch | |
| Network Management | Remote connections | 128 |
| Network protocols |
TCP/IP, PPPoE, DHCP,Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
|
| Hard Disk Driver | Interface Type | 1 SATA Interface |
| Capacity | Up to 6 TB capacity for each disk | |
| External Interface | Network Interface |
1; 10M / 100M self-adaptive Ethernet interface (TDV-5304/08-H1SV), 1; 10M / 100M/ 1000M self-adaptive Ethernet interface (TDV-5316-H1SV) |
| USB Interface | 2 USB 2.0 Interfaces (TDV-5304/08-H1SV); Front panel: 1 × USB 2.0 Rear panel: 1 × USB 3.0 (TDV-5316-H1SV) |
|
| Serial Interface | 1; standard RS-485 serial interface, half-duplex | |
| General | Power Supply | 12V DC |
| Consumption (without hdd) | TDV-5304-H1SV: ≤ 15W, TDV-5308-H1SV: ≤ 20W, TDV-5316-H1SV: ≤ 20W | |
| Working Temperature | -10 ºC ~+55 ºC (14 ºF ~ 131 ºF) | |
| Working Humidity | 10% ~ 90% | |
| Chassis | Standalone 1U chassis | |
| Dimensions | 315 × 242 × 45 mm | |
| (12.4 × 9.5 × 1.8 inch) | ||
| Weight | ≤2 kg(4.4lb) |
