Max 30fps@1080P
HD and SD output switchable
3.6mm fixed lens (2.8mm, 6mm optional)
Max. IR length 30m, Smart IR
IP67, DC12V
Description
| Camera | Image Sensor | 1/2.9" CMOS |
| Effective Pixels | 1920(H)×1080(V), 2MP | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | PAL: 1/25~1/100000s | |
| NTSC: 1/30~1/100000s | ||
| Minimum Illumination | 0.02Lux/F2.0, 0Lux IR on | |
| S/N Ratio | More than 65dB | |
| IR Distance | Up to 30m (98feet) | |
| IR LEDs | 12 | |
| Lens | Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in | |
| Focal Length | 3.6mm (2.8mm, 6mm Optional) | |
| Max Aperture | F2.0 | |
| Angle of View | H: 82.8° (106°/51.2°) | |
| Close Focus Distance | 800mm (500mm/1900mm) | |
| 31.5 (19.7/74.8) | ||
| Pan/Tilt/Rotation | Pan/Tilt/Rotation | Pan: 0° ~ 360° |
| Tilt: 0° ~ 90° | ||
| Rotation: 0° ~ 360° | ||
| Video | Resolution | 1080P (1920×1080) |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P | |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) | |
| Day/Night | Auto (ICR) / Manual | |
| BLC Mode | BLC / HLC / DWDR | |
| WDR | DWDR | |
| Gain Control | AGC | |
| Noise Reduction | 2D | |
| Certifications | Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | ||
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | ||
| Electrical | Power Supply | 12V DC ±25% |
| Power Consumption | Max 2.8W (12V DC, IR on) | |
| Environmental | Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH |
| * Start up should be done at above -40°C (-40°F) | ||
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH | |
| Ingress Protection &Vandal Resistance | IP67 | |
| Construction | Casing | Aluminium |
| Dimensions | Φ93.4mm×79.4mm (Φ3.68"×3.13") | |
| Net Weight | 0.28kg (0.62lb) | |
| Gross Weight | 0.35kg (0.77lb) |
