H.265/H.264 codec decoding
Max 80Mbps Incoming Bandwidth
Up to 8MP Resolution for Preview and Playback
HDMI/VGA simultaneous video output
Support ANR technology to enhance the storage reliability when the network break down
Description
| System | Main Processor | Quad-core embedded processor |
| Operating System | Embedded LINUX | |
| Display | Interface | 1 HDMI, 1 VGA |
| Resolution | 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 | |
| Multi-screen Display | 4CH: 1/4 | |
| 8CH: 1/4/8/9 | ||
| 16CH: 1/4/8/9/16 | ||
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
| Video Detection and Alarm | Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), | |
| Video Loss and Tampering | ||
| Playback and Backup | Playback | 4CH: 1/4 |
| 8CH: 1/4/8 | ||
| 16CH: 1/4/8/16 | ||
| Search Mode | Time /Date, MD and Exact Search | |
| (accurate to second), Smart search | ||
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, | |
| Next File, Previous File, Next Camera, | ||
| Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | ||
| Backup Mode | USB Device/Network | |
| Storage | Internal HDD | 1 SATA III Port, Up to 6 TB capacity for each HDD |
| HDD Mode | Single | |
| Auxiliary Interface | USB | 2 USB Ports (2 USB2.0) |
| Third-party Support | Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, |
| Canon, CP Plus, Dynacolor, Honeywell, Panasonic, | ||
| Pelco, Samsung, Sanyo, Sony, Videotec, and more | ||
| Audio and Video | IP Camera Input | 4/8/16 Channel |
| Two-way Talk | 1 Channel Input, 1 Channel Output, RCA | |
| Recording | Compression | H.265/H.264 |
| Resolution | 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. | |
| Record Rate | 80Mbps | |
| Bit Rate | 16Kbps ~ 20Mbps Per Channel | |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop | |
| Record Interval | 1 ~ 120 min (default: 60 min), Pre-record: | |
| 1 ~ 30 sec, Post-record: 10 ~ 300 sec | ||
| Network | Interface | 1 RJ-45 Port (10/100Mbps) |
| Ethernet Port | 1 Independent 100Mbps Ethernet Port | |
| PoE | N/A | |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, | |
| IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip | ||
| Max. User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 2.4, CGI Conformant | |
| Electrical | Power Supply | DC48V/1.5A |
| Power Consumption | NVR: | |
| Environmental | Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH | |
| Construction | Dimensions | Compact 1U, 260mm×224.9mm×47.6mm |
| (10.2" x 8.9" x 1.9") | ||
| Net Weight | 0.8kg (1.76 lb) (without HDD) | |
| Gross Weight | 1.6kg(3.53 lb)(without HDD) | |
| Certifications | CE | EN55032, EN55024, EN50130-4, EN60950-1 |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 | |
| UL | UL60950-1+CAN/CSA C22.2 No.60950-1 |
