-2MP high resolution
-HD real-time video
-DWDR&3DDNR
-EXIR illuminators: up to 30m
-IP66
-PoE
-Bracket included
Description
| Model | Infinity I-263 | |
| Camera | Image Sensor: | 1/3” Progressive Scan CMOS |
| Min. Illumination: | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
|
| Shutter Time: | 1/3 s to 1/100,000 s | |
| Lens: | 4 mm @ F2.0 (6mm, 16mm optional) Angle of view: 85° |
|
| Lens Mount: | M12 | |
| Day& Night: | ICR | |
| Digital noise reduction | 3D DNR | |
| Wide dynamic range | Digital WDR | |
| Compression Standard | Video compression | H.264 / MJPEG |
| H.264 codec profile | BaseLine Profile / Main Profile | |
| Bit rate | 32 Kbps ~ 12 Mbps | |
| Dual Stream | Yes | |
| Image | Max. Image Resolution | 1920 X 1080 |
| Frame rate | 50 Hz: 25fps(1920 × 1080), 25 fps (1280 ×960), 25 fps (1280 x 720) 60 Hz: 25fps(1920 × 1080), 30 fps (1280 ×960), 30 fps (1280 x 720 |
|
| Image settings | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
| Backlight compensation | Yes, zone optional | |
| ROI | Support | |
| Network | Network storage | NAS |
| Alarm trigger | Motion detection, tampering alarm, scene change detection, face detection, intrusion detection, Line crossing detection |
|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
|
| System compatibility | ONVIF, PSIA, CGI, ISAPI | |
| General functionalities | User Authentication, Watermark, IP address filtering, Anonymous access | |
| Interface | Communication interface | 1 RJ45 10M / 100M Ethernet interface |
| General | Operating conditions | -30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power supply | -I3: max. 5.5W -I5: max. 7W -I8: max 10W |
|
| Ingress protection leve | IP66 | |
| IR range | EXIR LED, up to 30m | |
| Dimensions | Φ105mm×300mm | |
| Weight | 1200g | |
