8/16-ch network cameras can be connected with 80m/160m incoming bandwidth
Up to 6MP resolution recording
HDMI and VGA output at up to 1920x1080P resolution'
2 SATA interfaces
Support network detection, including network delay, packet loss, etc
1x USB 2.0 and 1x USB 3.0
Description
| Model | NV-3308/3316 | |
| Video/Audio input |
IP video input | 8/16-ch |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1K ) | |
| Network | Incoming bandwidth | 80/160Mbps |
| Outgoing bandwidth | 80Mbps | |
| Remote connection | 32 (NV-3304), 128 (NV-3308 & 3316) | |
| Video/Audio output |
Recording resolution | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame rate | Main stream: 50 fps (P) / 60 fps (N) | |
| Sub-stream: 50 fps (P) / 60 fps (N) | ||
| HDMI/VGA output | 1-ch, resolution: 1920 × 1080 /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720/60Hz, 1024 × 768 /60Hz | |
| Audio output | 1-ch, RCA (Linear, 1k ) | |
| Decoding | Live view / Playback resolution |
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability | 4-ch@1080P | |
| 8-ch@720P, 6-ch@1080P |
||
| 16-ch@4CIF, 12-ch@720P, 6-ch@1080P |
||
| Hard disk | SATA | 2 SATA interface for 2 HDD |
| Capacity | Up to 4TB for each disk | |
| External interface |
Network interface | 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface |
| USB interface | 1 × USB 2.0 and 1 × USB 3.0 | |
| Alarm in/out (Optional) |
"4/1 | |
| Others | Power supply | 12V DC |
| Consumption (without hard disk) |
≤ 10W | |
| Working temperature |
"-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) | |
| Working humidity | 10 % ~ 90 % | |
| Chassis | Standalone 1U chassis | |
| Dimensions | 315 × 230 × 45 mm (12.4" × 9.0" × 1.8") | |
| Weight (without hard disk) | 1 kg (2.2 lb) | |
