• 1.3 Megapixel high-performance CMOS
• Analog HD output, up to 720P resolution
• True Day/Night
• 2.8 - 12mm vari-focal lens
• DNR, Smart IR
• Up to 40m IR distance
• IP66 weatherproof
Description
| Camera | ||
|---|---|---|
| Image Sensor: | | | 1.3MP CMOS Image Sensor |
| Signal System: | | | PAL/NTSC |
| Effective Pixels: | | | 1280(H)x960(V) |
| Min. Illumination: | | | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time: | | | 1/25(1/30) s to 1/50,000 s |
| Lens: | | | 2.8-12mm @ F1.4 Angle of view: 97° - 30.4° |
| Lens Mount: | | | φ14 |
| Adjustment Range: | | | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night: | | | IR cut filter with auto switch |
| Video Frame Rate: | | | 720p@25fps/720p@30fps |
| HD Video Output: | | | 1 Analog HD output |
| Synchronization: | | | Internal Synchronization |
| S/N Ratio: | | | More than 62 dB |
| Menu | ||
| Auto White Balance: | | | Auto / Manual |
| General | ||
| Operating Conditions: | | | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply: | | | 12 VDC±15% |
| Power Consumption: | | | Max. 4W |
| Weather Proof: | | | IP66 |
| IR Range: | | | Up to 40m |
| Communication : | | | Up the coax Protocol: Pelco-C(CVBS output), HIKVISION-C(TVI output) |
| Dimension: | | | 92 × 84.8 × 269.6mm(3.62” × 3.34” × 10.6”) |
| Weight: | | | 1000 g |
| Ukuran (L X W X H cm) | 0x0x0 |
| Berat (kg) | 0.00 |
